滤纸滤膜

概述Overview
微孔滤膜根据所过滤溶剂的化学性质正确的选择滤膜对于达到理想的过滤效果至关重要。
在膜分离技术应用中，微孔滤膜是应用范围较广的一种膜品种，使用简单快捷。可作为一般料液的澄清、保安过滤、空气除菌。广泛应用科研、医药卫生、生物化学、食品、能源、微电子工业、纳米技术、环境保护等部门。其气通量大、高微粒截留率、耐温性好，抗强酸、强碱、有机溶剂和氧化剂，耐老化及不粘、不燃性和无毒、生物相容性好等特点。其材质分为有机和无机两大类，鉴于微孔滤膜的分离特征，微孔滤膜的应用范围主要是从气相和液相中截留微粒、细菌以及其他污染物，以达到净化、分离、浓缩的目的。对于微滤而言，膜的截留特性是以膜的孔径来表征，通常孔径范围在0.1~1μm,故微滤膜能对大直径的菌体、悬浮固体等进行分离。
The correct selection of flter membrane is crucial for achieving ideal filtration results based on thechemical properties of the solvent beingfitered.
In the application of membrane separation technology,mieroporous filter membrane is a kind ofmembranewith a wide range ofapplications,whichis andquick to ue.Itcan be used for the clarificationof general materials,security filtration,and air sterilization.It is widely used in scientific research,medical health,biochemistry fod energy,mieroelectronics industry,nanotechnology,environmentalprotection and other departments.It hasthe characteristicsoflarge gas permeability,high retention rate,good temperature resistance,strong acid,stron alkali,organic solvents and oxidants,anti-aging andnon-adhesion,non-flammability non-toxicity,and good biocompatibility.Its material is divided intoorganic and inorganic categories.In view of the separation characterisics of microporous filter,theapplicationscope of microporousfilter membrane is mainlyto retain microparticles,bacteria and otherpollutants from gas and liguid phases,so as to achieve the of purification,separation and concentration.For microfiltration,the retention characteristics of the membrane arecharacteized by the pore size ofthe membrane,and the pore size range usually 0.1 to 1 μm,so the microfiltration membrane canseparae large-diameter bacteria,suspended slids,ete

各类微孔滤膜特性Characteristis fvarious mieroporous fier membranes
1、尼龙膜
特点：耐温性能良好，可耐121℃饱和蒸汽热压消毒30min,工作温度60度以下，化学稳定良好，能耐受稀酸、稀碱、醇类、酯类、油类、碳氢化合物、卤代烃及有机氧化物等多种有机和无机化合物。
用途：电子、微电子、半导体工业水过滤、组织培养基过滤，药液过滤、饮料过滤、高纯化学制品过滤，水溶液和有机流动相的过滤。
1.Nylon membrane
Features Good temperature resistance,can withstand 121C saturated steam heat pres sterilization for 30min working temperature below 60degres,good chemicalstability can withstand dilute acid,dilute alkali,alcohols,esters,oils,hydrobons,halogenated hydrocarbons and organicoxidesand ocher organican inorganic compounds.
Uses:Water filration in electronics,microelectronics,semiconductor indutries,culture medium fitration,Filtration of medicinal solutions,beverageflration,high purity chemical productsfiltration,Filtration ofaqueous solutions and organic mobile phases

2、聚偏氟乙烯膜
特点：膜机械强度高、抗张强度高，具有良好的耐热性和化学稳定性，蛋白吸附率低；具有较强的负静电性及疏水性；具有疏水和亲水两种形式。但不能耐受丙酮，DMSO,THF,DMF,二氯甲烷，氯仿等。

用途：疏水性聚偏氟乙烯膜主要应用于气体及蒸汽过滤、高温液体的过滤；亲水性聚偏氟乙烯膜主要应用于组织培养基、添加剂等除菌过滤溶剂和化学原料的净化过滤，试剂的无菌处理，高温液体的过滤等。
2、Polyvinylidene fluoride membrane
Features:The membrane has high mechanical strength,high tensile strength,good heat resistance and stability,low protein adsorption rate it has trongnegative static electrity and hydrophobicity;it has two forms ofhydrophobi and hydrophilie,it cannotwithstand acetone,DMSO,THE,DME,dichloro-methane,chloroform,etc.
Uses Hydrophobievinylidene fluoride membrane is mainly used for gas and steam fltration,high-temperature liguidfltration;hydrophilie polyinylidenefluoride membrane is mainlyforsterilization fitration oftisue culture medium,aditives,ete.,purificationfiltration ofsolventsand chemical raw materials,asepti treatment ofreagents,high-liguid filtration,etc.

3、混合纤维素酯
特点：孔径比较均匀，孔隙率高，无介质脱落，质地薄，阻力小，滤速快，吸附极小，使用价格成本低，但不耐有机溶液和强酸、强碱溶液。
用途：医药工业需热压灭菌的水针剂，大输液滤除微粒。对热敏性药物(胰岛素ATP、酶A等生化制剂)的除菌，用0.45微米的滤膜(或0.22)溶液中微粒及油类不溶物的分析测定，及水质污染指数测定。应用于体细胞杂交和线粒互补预测杂种优势研究等科研部门。
3、Mixed cellulose ester
Features Uniform pore size,igh porosity,no medium sheding,thin texture low resistance,fastfilration sped,cxtremely small dsorption,low cost,butnot resistant to organic solvents an strongacids and alkalis.
Uses For water injectablesin the pharmaceuticalindustry that ned tobe strilized byheat pressing,and for the removalof particlesinlarge infusions.For thesterilization of heat drugs (insulin ATP,enzyme A,etc.biochemical preparations),the analysis and determination of particlesand oil-insolublesubstances insolutions and the determination of pollutionindex.It is also used in scientific reseach departments such as somatic cellhybridization and mitochondrialcomplementation to predict hybrid vigor.

4、聚丙烯
特点：无任何粘接剂，化学性能稳定，柔韧，不易破损，耐高温，能经受高压灭菌。无毒无味，耐酸碱。
用途：适用于制作各种粗、精滤器，折叠式滤芯。适用于饮料、医药等行业的板框压滤机滤膜。适用于反渗透膜，超滤膜的支撑及预处理。
聚丙烯膜无毒性，可在医药、化工、食品、饮料等领域广泛应用；具疏水性，对气体过滤尤佳。
4、Polypropylene(PP)
Features No any binder,stable chemicalperformance,flexible,not easy to damage,resistant to high temperature,can withstand high-presure sterilization.Non-toxic tasteles,resistant to acid and alkali.
Uses Suitable for making various coarse and fine filters,pleatedflter cores.Suitable for the filter membrane of plate frame filter pressin the beverage andpharmaceutical industries.Suitable forthe support and pretreatment of reverse osmosis membrane and ultrafiltration membrane.Polypropylene membrane non-toxic and canbe widey used in pharmaceutical,chemical,food,beverage and other fields it has hydrophobicity,which isespeciallysuitable for gas.

5、聚醚砜
特点：聚醚砜材质的微孔滤膜，属于亲水性滤膜，具有高流率、低溶出物、良好的强度的特点不吸附蛋白和提取物，对样品无污染。
用途：低蛋白质吸附及高药物相容性，专为生化、检验、制药以及除菌过滤装置而设计。
5、Polyether sulfone
Features The microfiltration membrane made of ether sulfone material is a bydrophilie fiter membrane,which has the characteristics hig flow rate,low
extractables,and good strength.Itdoes not adsorb proteins and extracts,and does not contaminate samples.
Uses Low proteinorption andhigh drugcompatibility,especilly designed forbiochemical,testing pharmaceutical,and sterilization fltration devices.

6、聚四氟乙烯
特点：较广泛的化学兼容性，能耐受DMSO,THF,DMF,二氯甲烷，氯仿等强溶剂。应用：所有有机溶液的过滤，特别是其它滤膜不能耐受的强溶剂的过滤。
6、PolytetrafluoroethyleneFeatures Bro chemical compatibility,canwithstand strongsolvents such as DMSO.THE,DMF,dichloromethane,chloroform,etc.Application:Filtration ofalforganic solutions,especiallystrong solvents that other filter membranes cannot withstand.
