KYC过滤洗涤二合一过滤机

设计原理Design Principles
1、整个筒体按照压力容器设计与制作。
2、其整个工作过程可以在一个密闭的环境内进行。
3、在过滤阶段主要是靠罐体底部抽真空，为了提高过滤效率在罐体内可以施加正压，一般不超过0.1MPa。
4、在滤饼抽干后，由于滤饼密度较高，为了使其疏松，靠S型桨叶的反切和升降可以把滤饼刮松。
5、在洗涤过程中，由S型桨叶的正转和升降将起了搅拌作用，使洗涤液与物料充分洗涤。
6、底盘与筒体设计可拆卸式，在底盘上铺上支承网和冲孔板一则便于液体流动，二则便于安装滤布。
7、过滤介质可以用滤布、无纺布、也可以用烧结网。
8、卸料是通过S型桨叶反推动使物料从侧出料口自动卸出。
9、搅拌的正反转是通过电机减速机带动主轴转动调节液压阀完成升降的速度，减速机可选国产和进口的。
1.The whole cylinder is designed and manufactured according to pressure vessel.
2.The whole working process can be caried out in a closed environment.

3.In the filtration stage,it mainly relies on the vacuum at the bottom of the tank,and in order to improve the filtrationcefficiency,positive pressure can be applied in the tank,which is generally not more than0.1MPa.

4.Ater the cake is drained,due to the high density of the cake,in order toloosen it,the cake can be scraped loose by thereverse cutting and lifing of the S-shaped blade.

5.Inthe washing process,the positive rotation and liting of the S-shaped blade will play a stirring role,so that the washingliquid and materials are fully washed.

6.The chassis and cylinder are designed to be removable,and the supporting net and punching plate are laid on the chassisto facilitate liquid flow,and the filter cloth is easy to install.

7.The filter medium can be filter cloth,non-woven fabric,or sintered mesh.

8.The material is automatically discharged from the side discharge port by the S-shaped blade pushing back.

9.The forward and reverse rotation of stirring is to drive the spindle to rotate and adjust the speed of the hydraulic valve tocomplete the lifing through the motor reducer,and the reducer can be selected from domestic and imported.

材质：碳钢、不锈钢、钛材、哈氏合金、衬塑或复合材料等

Material:carbon steel,stainles stel,titanium,Hastelloy,Teflon or composite materials,etc.
